mln::hexa< I > Struct Template Reference
[Domain morphers]
hexagonal image class.
More...
#include <hexa.hh>
Public Types | |
| typedef hexa_bkd_piter_< box2d > | bkd_piter |
| FIXME : should it be in box2d_h? Backward Site_Iterator associated type. | |
| typedef Image< void > | category |
| typedef I | delegatee |
| Delegatee associated type. | |
| typedef S | domain_t |
| Site_Set associated type. | |
| typedef E | exact_t |
| typedef hexa_fwd_piter_< box2d > | fwd_piter |
| FIXME : should it be in box2d_h? Forward Site_Iterator associated type. | |
| typedef I::lvalue | lvalue |
| Lvalue associated type. | |
| typedef fwd_piter | piter |
| Site_Iterator associated type; default definition is fwd_piter. | |
| typedef point2d_h | psite |
| Point site type. | |
| typedef I::rvalue | rvalue |
| Return type of read-only access. | |
| typedef S::site | site |
| Site associated type. | |
| typedef hexa< tag::image_< I > > | skeleton |
| Skeleton. | |
| typedef mln::value::set< I::value > | t_eligible_values_set |
| Eligible-value-set associated type. | |
| typedef mln::value::set < typename mln::value::super_value < I::value >::ret > | t_values_space |
| Value space associated type. | |
| typedef I | unmorph |
| Unmorph image associated type. | |
| typedef I::value | value |
| Value associated type. | |
Public Member Functions | |
| I * | delegatee_ () |
| Return the delegatee_ pointer (non-const version); default code. | |
| mln::metal::const_< I >::ret * | delegatee_ () const |
| Return the delegatee_ pointer; default code. | |
| void | destroy () |
| Detach data from an image (free it if nobody else hold it). | |
| const box2d_h & | domain () const |
| Give the definition domain. | |
| bool | has (const psite &p) const |
Test if p belongs to the image domain. | |
| bool | has (const psite &p) const |
Test if p belongs to the image domain. | |
| hexa (I &ima) | |
| Constructor with an base image. | |
| hexa () | |
| Constructor without argument. | |
| const util::tracked_ptr < internal::data< E > > & | hook_data_ () const |
| Hook to the image data. | |
| const void * | id_ () const |
| Give an identifier of this image. | |
| template<typename P> | |
| unsigned | index_of_point (const P &p) const |
Give the offset of the site p. | |
| void | init_ (I &ima) |
| Initialization. | |
| bool | is_valid () const |
| Test if this image has been initialized; default impl. | |
| std::size_t | nsites () const |
| Give the number of sites of the image domain. | |
| lvalue | operator() (const typename S::psite &p) |
Read and "write if possible" access of pixel value at point site p. | |
| rvalue | operator() (const typename S::psite &p) const |
Read-only access of pixel value at point site p. | |
| lvalue | operator() (const point2d_h &p) |
Read-write access of pixel value at hexa point site p. | |
| rvalue | operator() (const point2d_h &p) const |
Read-only access of pixel value at hexa point site p. | |
| E & | rw () |
| State that the morpher is writable. | |
| mln::metal::const_< I >::ret & | unmorph_ () const |
| Give the morphed image (const version). | |
| I & | unmorph_ () |
| Give the morphed image (mutable version). | |
| const t_eligible_values_set & | values_eligible () const |
| const t_values_space & | values_space () const |
| Return the value space of the image. | |
Protected Attributes | |
| util::tracked_ptr < internal::data< E > > | data_ |
Detailed Description
template<typename I>
struct mln::hexa< I >
hexagonal image class.
The parameter I is the type of the base image. This image class which handles hexagonal grid.
Ex : 1 3 5 7 9 11 0 2 4 6 8 10 ------------------- 0 XX| | | | | | |XX --------------------- 2 XX| | | | | | |XX --------------------- 4 XX| | | | | | |XX --------------------- 6 XX| | | | | | |XX --------------------- 8 XX| | | | | | |XX -------------------
Definition at line 116 of file hexa.hh.
Member Typedef Documentation
| typedef hexa_bkd_piter_<box2d> mln::hexa< I >::bkd_piter |
FIXME : should it be in box2d_h? Backward Site_Iterator associated type.
Reimplemented from mln::internal::image_base< I::value, S, E >.
typedef Image<void> mln::Image< E >::category [inherited] |
typedef I mln::internal::image_morpher< I , I::value , S , E >::delegatee [inherited] |
typedef S mln::internal::image_base< I::value , S , E >::domain_t [inherited] |
typedef E mln::Object< E >::exact_t [inherited] |
| typedef hexa_fwd_piter_<box2d> mln::hexa< I >::fwd_piter |
FIXME : should it be in box2d_h? Forward Site_Iterator associated type.
Reimplemented from mln::internal::image_base< I::value, S, E >.
typedef fwd_piter mln::internal::image_base< I::value , S , E >::piter [inherited] |
Site_Iterator associated type; default definition is fwd_piter.
Reimplemented in mln::ch_piter_image< I, Fwd >.
Definition at line 123 of file core/internal/image_base.hh.
Point site type.
Reimplemented from mln::internal::image_base< I::value, S, E >.
Reimplemented in mln::image2d_h< V >.
typedef S ::site mln::internal::image_base< I::value , S , E >::site [inherited] |
Site associated type.
Reimplemented in mln::tr_image< S, I, T >.
Definition at line 111 of file core/internal/image_base.hh.
| typedef hexa< tag::image_<I> > mln::hexa< I >::skeleton |
typedef mln::value::set<I::value > mln::internal::image_base< I::value , S , E >::t_eligible_values_set [inherited] |
typedef mln::value::set< typename mln::value::super_value<I::value >::ret > mln::internal::image_base< I::value , S , E >::t_values_space [inherited] |
typedef I mln::internal::image_morpher< I , I::value , S , E >::unmorph [inherited] |
Constructor & Destructor Documentation
Constructor with an base image.
Definition at line 222 of file hexa.hh.
References mln::hexa< I >::init_().
Member Function Documentation
| I * mln::internal::image_morpher< I , I::value , S , E >::delegatee_ | ( | ) | [inherited] |
Return the delegatee_ pointer (non-const version); default code.
| mln::metal::const_< I >::ret* mln::internal::image_morpher< I , I::value , S , E >::delegatee_ | ( | ) | const [inherited] |
Return the delegatee_ pointer; default code.
Referenced by mln::internal::image_identity< I, S, E >::domain(), mln::tr_image< S, I, T >::has(), mln::internal::image_identity< I, S, E >::has(), mln::tr_image< S, I, T >::is_valid(), mln::transformed_image< I, F >::operator()(), mln::internal::image_identity< I, S, E >::operator()(), mln::internal::image_domain_morpher< I, S, E >::operator()(), and mln::decorated_image< I, D >::operator()().
| void mln::internal::image_base< I::value , S , E >::destroy | ( | ) | [inherited] |
Detach data from an image (free it if nobody else hold it).
Referenced by mln::plain< I >::operator=().
Give the definition domain.
Definition at line 250 of file hexa.hh.
References mln::internal::image_base< I::value, S, E >::data_, and mln::internal::image_morpher< I, I::value, S, E >::is_valid().
| bool mln::internal::image_base< I::value , S , E >::has | ( | const psite & | p | ) | const [inherited] |
Test if p belongs to the image domain.
Referenced by mln::unproject_image< I, D, F >::operator()(), mln::transformed_image< I, F >::operator()(), mln::slice_image< I >::operator()(), mln::p2p_image< I, F >::operator()(), and mln::internal::image_domain_morpher< I, S, E >::operator()().
Test if p belongs to the image domain.
Definition at line 259 of file hexa.hh.
References mln::internal::image_base< I::value, S, E >::data_, and mln::internal::image_morpher< I, I::value, S, E >::is_valid().
Referenced by mln::hexa< I >::operator()().
| const util::tracked_ptr< internal::data<E > >& mln::internal::image_base< I::value , S , E >::hook_data_ | ( | ) | const [inherited] |
| const void* mln::internal::image_base< I::value , S , E >::id_ | ( | ) | const [inherited] |
Give an identifier of this image.
When several image variables designate the same image, they share the same identifier.
| unsigned mln::internal::check::image_fastest_< E, B >::index_of_point | ( | const P & | p | ) | const [inline, inherited] |
Give the offset of the site p.
- Parameters:
-
[in] p A site.
- Warning:
- This method is final.
- Precondition:
- The image has to be initialized and to own the point
p.
- Postcondition:
- p == point_at_index(result)
Definition at line 133 of file internal/check/image_fastest.hh.
| void mln::hexa< I >::init_ | ( | I & | ima | ) | [inline] |
Initialization.
Definition at line 203 of file hexa.hh.
References mln::make::box2d_h(), mln::internal::image_base< I::value, S, E >::data_, mln::internal::image_morpher< I, I::value, S, E >::is_valid(), mln::box< P >::pmax(), and mln::box< P >::pmin().
Referenced by mln::hexa< I >::hexa(), mln::image2d_h< V >::image2d_h(), and mln::init_().
| bool mln::internal::image_morpher< I , I::value , S , E >::is_valid | ( | ) | const [inherited] |
Test if this image has been initialized; default impl.
Reimplemented from mln::internal::image_base< I::value, S, E >.
Reimplemented in mln::interpolated< I, F >, and mln::tr_image< S, I, T >.
Referenced by mln::extension_val< I >::change_extension(), mln::decorated_image< I, D >::decorated_image(), mln::unproject_image< I, D, F >::domain(), mln::slice_image< I >::domain(), mln::p2p_image< I, F >::domain(), mln::image_if< I, F >::domain(), mln::hexa< I >::domain(), mln::extended_to(), mln::extension_val< I >::extension(), mln::extension_ima< I, J >::extension(), mln::extension_fun< I, F >::extension(), mln::p2p_image< I, F >::fun(), mln::hexa< I >::has(), mln::extension_ima< I, J >::has(), mln::unproject_image< I, D, F >::init_(), mln::transformed_image< I, F >::init_(), mln::sub_image_if< I, S >::init_(), mln::sub_image< I, S >::init_(), mln::slice_image< I >::init_(), mln::safe_image< I >::init_(), mln::p2p_image< I, F >::init_(), mln::image_if< I, F >::init_(), mln::hexa< I >::init_(), mln::extended< I >::init_(), mln::decorated_image< I, D >::init_(), mln::make::labeled_image(), mln::plain< I >::operator I(), mln::image_if< I, F >::operator image_if< const I, F >(), mln::slice_image< I >::operator slice_image< const I >(), mln::hexa< I >::operator()(), mln::extension_ima< I, J >::operator()(), mln::extension_fun< I, F >::operator()(), mln::plain< I >::operator=(), mln::plain< I >::plain(), and mln::slice_image< I >::sli().
| std::size_t mln::internal::image_base< I::value , S , E >::nsites | ( | ) | const [inherited] |
Give the number of sites of the image domain.
| image_domain_morpher< I, S, E >::lvalue mln::internal::image_domain_morpher< I, S, E >::operator() | ( | const typename S::psite & | p | ) | [inline, inherited] |
Read and "write if possible" access of pixel value at point site p.
Definition at line 97 of file image_domain_morpher.hh.
References mln::internal::image_morpher< I, I::value, S, E >::delegatee_(), mln::exact(), and mln::internal::image_base< I::value, S, E >::has().
| I::rvalue mln::internal::image_domain_morpher< I, S, E >::operator() | ( | const typename S::psite & | p | ) | const [inline, inherited] |
Read-only access of pixel value at point site p.
Definition at line 86 of file image_domain_morpher.hh.
References mln::exact().
Read-write access of pixel value at hexa point site p.
Definition at line 240 of file hexa.hh.
References mln::internal::image_base< I::value, S, E >::data_, mln::hexa< I >::has(), and mln::internal::image_morpher< I, I::value, S, E >::is_valid().
| hexa< I >::rvalue mln::hexa< I >::operator() | ( | const point2d_h & | p | ) | const [inline] |
Read-only access of pixel value at hexa point site p.
Definition at line 230 of file hexa.hh.
References mln::internal::image_base< I::value, S, E >::data_, mln::hexa< I >::has(), and mln::internal::image_morpher< I, I::value, S, E >::is_valid().
| E & mln::internal::image_morpher< I , I::value , S , E >::rw | ( | ) | [inherited] |
State that the morpher is writable.
This allows for C++ to use it as a mutable object even if it is a temporary object.
| mln::metal::const_< I >::ret& mln::internal::image_morpher< I , I::value , S , E >::unmorph_ | ( | ) | const [inherited] |
Give the morphed image (const version).
| I & mln::internal::image_morpher< I , I::value , S , E >::unmorph_ | ( | ) | [inherited] |
Give the morphed image (mutable version).
| const t_eligible_values_set& mln::internal::image_base< I::value , S , E >::values_eligible | ( | ) | const [inherited] |
| const t_values_space& mln::internal::image_base< I::value , S , E >::values_space | ( | ) | const [inherited] |
Return the value space of the image.
Member Data Documentation
util::tracked_ptr< internal::data<E > > mln::internal::image_base< I::value , S , E >::data_ [protected, inherited] |
Definition at line 163 of file core/internal/image_base.hh.
Referenced by mln::labeled_image_base< I, E >::bbox(), mln::labeled_image_base< I, E >::bboxes(), mln::extension_val< I >::change_extension(), mln::decorated_image< I, D >::decorated_image(), mln::decorated_image< I, D >::decoration(), mln::unproject_image< I, D, F >::domain(), mln::transformed_image< I, F >::domain(), mln::tr_image< S, I, T >::domain(), mln::sub_image_if< I, S >::domain(), mln::sub_image< I, S >::domain(), mln::slice_image< I >::domain(), mln::p2p_image< I, F >::domain(), mln::lazy_image< I, F, B >::domain(), mln::image_if< I, F >::domain(), mln::hexa< I >::domain(), mln::extended< I >::domain(), mln::extension_val< I >::extension(), mln::extension_ima< I, J >::extension(), mln::extension_fun< I, F >::extension(), mln::p2p_image< I, F >::fun(), mln::tr_image< S, I, T >::has(), mln::lazy_image< I, F, B >::has(), mln::interpolated< I, F >::has(), mln::hexa< I >::has(), mln::extension_ima< I, J >::has(), mln::unproject_image< I, D, F >::init_(), mln::transformed_image< I, F >::init_(), mln::tr_image< S, I, T >::init_(), mln::sub_image_if< I, S >::init_(), mln::sub_image< I, S >::init_(), mln::slice_image< I >::init_(), mln::safe_image< I >::init_(), mln::plain< I >::init_(), mln::p2p_image< I, F >::init_(), mln::lazy_image< I, F, B >::init_(), mln::labeled_image< I >::init_(), mln::interpolated< I, F >::init_(), mln::image_if< I, F >::init_(), mln::hexa< I >::init_(), mln::extension_val< I >::init_(), mln::extension_ima< I, J >::init_(), mln::extension_fun< I, F >::init_(), mln::extended< I >::init_(), mln::decorated_image< I, D >::init_(), mln::ch_piter_image< I, Fwd >::init_(), mln::labeled_image< I >::init_from_(), mln::interpolated< I, F >::is_valid(), mln::labeled_image< I >::labeled_image(), mln::lazy_image< I, F, B >::lazy_image(), mln::decorated_image< I, D >::operator decorated_image< const I, D >(), mln::plain< I >::operator I(), mln::image_if< I, F >::operator image_if< const I, F >(), mln::safe_image< I >::operator safe_image< const I >(), mln::slice_image< I >::operator slice_image< const I >(), mln::sub_image< I, S >::operator sub_image< const I, S >(), mln::transformed_image< I, F >::operator transformed_image< const I, F >(), mln::unproject_image< I, D, F >::operator()(), mln::transformed_image< I, F >::operator()(), mln::tr_image< S, I, T >::operator()(), mln::slice_image< I >::operator()(), mln::p2p_image< I, F >::operator()(), mln::hexa< I >::operator()(), mln::extension_ima< I, J >::operator()(), mln::extension_fun< I, F >::operator()(), mln::plain< I >::operator=(), mln::plain< I >::plain(), mln::decorated_image< I, D >::read_(), mln::labeled_image_base< I, E >::relabel(), mln::tr_image< S, I, T >::set_tr(), mln::slice_image< I >::sli(), mln::labeled_image_base< I, E >::subdomain(), mln::tr_image< S, I, T >::tr(), and mln::labeled_image_base< I, E >::update_data().
