Image based on a complex. More...

#include <complex_image.hh>

Inheritance diagram for mln::complex_image< D, G, V >:

Public Types
typedef p_complex< D, G > ::bkd_piter	bkd_piter
	Backward Site_Iterator associated type.
typedef Image< void >	category
typedef p_complex< D, G >	domain_t
	Site_Set associated type.
typedef complex_image< D, G, V >	exact_t
typedef p_complex< D, G > ::fwd_piter	fwd_piter
	Forward Site_Iterator associated type.
typedef G	geom
	The geometry type of the complex.
typedef std::vector< V >::reference	lvalue
	Return type of read-write access.
typedef fwd_piter	piter
	Site_Iterator associated type; default definition is fwd_piter.
typedef p_complex< D, G >::psite	psite
	Point_Site associated type.
typedef std::vector< V > ::const_reference	rvalue
	Return type of read-only access.
typedef p_complex< D, G >::site	site
	Site associated type.
typedef complex_image< D, tag::psite_< G >, tag::value_ < V > >	skeleton
	Skeleton.
typedef mln::value::set< V >	t_eligible_values_set
	Eligible-value-set associated type.
typedef mln::value::set < typename mln::value::super_value< V > ::ret >	t_values_space
	Value space associated type.
typedef V	value
	Value associated type.
Public Member Functions
void	destroy ()
	Detach data from an image (free it if nobody else hold it).
bool	has (const psite &p) const
	Test if `p` belongs to the image domain.
const util::tracked_ptr < internal::data < complex_image< D, G, V > > > &	hook_data_ () const
	Hook to the image data.
const void *	id_ () const
	Give an identifier of this image.
unsigned	index_of_point (const P &p) const
	Give the offset of the site `p`.
void	init_ (const p_complex< D, G > &pc, const metal::vec< D+1, std::vector< V > > &values)
	Initialize an empty image.
bool	is_valid () const
	Test if this image has been initialized; default impl.
std::size_t	nsites () const
	Give the number of sites of the image domain.
lvalue	operator() (const complex_psite< D, G > &p)
	Read-write access of face value at point site `p`.
rvalue	operator() (const complex_psite< D, G > &p) const
	Read-only access of face value at point site `p`.
const t_eligible_values_set &	values_eligible () const
const t_values_space &	values_space () const
	Return the value space of the image.


	complex_image ()
	Constructors.
	complex_image (const p_complex< D, G > &pc)
	complex_image (const p_complex< D, G > &pc, const metal::vec< D+1, std::vector< V > > &values)


const p_complex< D, G > &	domain () const
	Accessors.
const metal::vec< D+1, std::vector< V > > &	values () const
	Return the array of values associated to the faces.
Static Public Attributes
static const unsigned	dim = D
	The dimension of the complex.
Protected Attributes
util::tracked_ptr < internal::data < complex_image< D, G, V > > >	data_

Detailed Description

template<unsigned D, typename G, typename V>
class mln::complex_image< D, G, V >

Image based on a complex.

Values attached to each face of the complex.

Template Parameters:

	D	The dimension of the complex.
	G	The geometry type of the complex.
	V	The value type of the image.

Member Typedef Documentation

typedef p_complex< D, G > ::bkd_piter mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::bkd_piter [inherited]

Backward Site_Iterator associated type.

typedef Image<void> mln::Image< complex_image< D, G, V > >::category [inherited]

Reimplemented from mln::Object< complex_image< D, G, V > >.

typedef p_complex< D, G > mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::domain_t [inherited]

Site_Set associated type.

typedef complex_image< D, G, V > mln::Object< complex_image< D, G, V > >::exact_t [inherited]

typedef p_complex< D, G > ::fwd_piter mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::fwd_piter [inherited]

Forward Site_Iterator associated type.

template<unsigned D, typename G, typename V>

typedef G mln::complex_image< D, G, V >::geom

The geometry type of the complex.

template<unsigned D, typename G, typename V>

typedef std::vector<V>::reference mln::complex_image< D, G, V >::lvalue

Return type of read-write access.

We use the associated type reference instead of a plain reference on the value type (V), because it's the only way to safely form a reference on the element in the case of a std::vector<bool>.

typedef fwd_piter mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::piter [inherited]

Site_Iterator associated type; default definition is fwd_piter.

typedef p_complex< D, G > ::psite mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::psite [inherited]

Point_Site associated type.

template<unsigned D, typename G, typename V>

typedef std::vector<V>::const_reference mln::complex_image< D, G, V >::rvalue

Return type of read-only access.

typedef p_complex< D, G > ::site mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::site [inherited]

Site associated type.

template<unsigned D, typename G, typename V>

typedef complex_image< D, tag::psite_<G>, tag::value_<V> > mln::complex_image< D, G, V >::skeleton

Skeleton.

typedef mln::value::set<V > mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::t_eligible_values_set [inherited]

Eligible-value-set associated type.

typedef mln::value::set< typename mln::value::super_value<V >::ret > mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::t_values_space [inherited]

Value space associated type.

template<unsigned D, typename G, typename V>

typedef V mln::complex_image< D, G, V >::value

Value associated type.

Reimplemented from mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >.

Constructor & Destructor Documentation

template<unsigned D, typename G , typename V >

mln::complex_image< D, G, V >::complex_image ( ) [inline]

Constructors.

template<unsigned D, typename G, typename V >

mln::complex_image< D, G, V >::complex_image ( const p_complex< D, G > & pc ) [inline]

References mln::p_complex< D, G >::cplx(), and mln::complex_image< D, G, V >::init_().

template<unsigned D, typename G, typename V>

mln::complex_image< D, G, V >::complex_image	(	const p_complex< D, G > &	pc,
		const metal::vec< D+1, std::vector< V > > &	values
	)			`[inline]`

References mln::complex_image< D, G, V >::init_(), and mln::complex_image< D, G, V >::values().

Member Function Documentation

void mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::destroy ( ) [inherited]

Detach data from an image (free it if nobody else hold it).

template<unsigned D, typename G , typename V >

const p_complex< D, G > & mln::complex_image< D, G, V >::domain ( ) const [inline]

Accessors.

Return the domain of psites od the image.

References mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::data_, and mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::is_valid().

Referenced by mln::init_().

bool mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::has ( const psite & p ) const [inherited]

Test if p belongs to the image domain.

Referenced by mln::make::attachment(), and mln::make::detachment().

const util::tracked_ptr< internal::data<complex_image< D, G, V > > >& mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::hook_data_ ( ) const [inherited]

Hook to the image data.

const void* mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::id_ ( ) const [inherited]

Give an identifier of this image.

When several image variables designate the same image, they share the same identifier.

unsigned mln::internal::check::image_fastest_< complex_image< D, G, V > , mln::metal::equal< mln_trait_image_speed(complex_image< D, G, V >), trait::image::speed::fastest >::eval >::index_of_point ( const P & p ) const [inherited]

Give the offset of the site p.

Parameters:

[in] p A site.

Warning:: This method is final.

Precondition:: The image has to be initialized and to own the point p.

Postcondition:: p == point_at_index(result)

template<unsigned D, typename G, typename V>

void mln::complex_image< D, G, V >::init_	(	const p_complex< D, G > &	pc,
		const metal::vec< D+1, std::vector< V > > &	values
	)			`[inline]`

Initialize an empty image.

References mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::data_, and mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::is_valid().

Referenced by mln::complex_image< D, G, V >::complex_image(), and mln::init_().

bool mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::is_valid ( ) const [inherited]

Test if this image has been initialized; default impl.

Referenced by mln::complex_image< D, G, V >::domain(), and mln::complex_image< D, G, V >::init_().

std::size_t mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::nsites ( ) const [inherited]

Give the number of sites of the image domain.

template<unsigned D, typename G, typename V >

complex_image< D, G, V >::rvalue mln::complex_image< D, G, V >::operator() ( const complex_psite< D, G > & p ) const [inline]

Read-only access of face value at point site p.

References mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::data_, mln::complex_psite< D, G >::face_id(), and mln::complex_psite< D, G >::n().

template<unsigned D, typename G, typename V >

complex_image< D, G, V >::lvalue mln::complex_image< D, G, V >::operator() ( const complex_psite< D, G > & p ) [inline]

Read-write access of face value at point site p.

References mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::data_, mln::complex_psite< D, G >::face_id(), and mln::complex_psite< D, G >::n().

template<unsigned D, typename G , typename V >

const metal::vec< D+1, std::vector< V > > & mln::complex_image< D, G, V >::values ( ) const [inline]

Return the array of values associated to the faces.

References mln::internal::image_base< V, p_complex< D, G >, complex_image< D, G, V > >::data_.

Referenced by mln::complex_image< D, G, V >::complex_image(), and mln::init_().

const t_eligible_values_set& mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::values_eligible ( ) const [inherited]

const t_values_space& mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::values_space ( ) const [inherited]

Return the value space of the image.

Member Data Documentation

util::tracked_ptr< internal::data<complex_image< D, G, V > > > mln::internal::image_base< V , p_complex< D, G > , complex_image< D, G, V > >::data_ [protected, inherited]

Referenced by mln::complex_image< D, G, V >::domain(), mln::complex_image< D, G, V >::init_(), mln::complex_image< D, G, V >::operator()(), and mln::complex_image< D, G, V >::values().

template<unsigned D, typename G, typename V>

const unsigned mln::complex_image< D, G, V >::dim = D [static]

The dimension of the complex.
